6ES7216-2BF21-0XB0 CPU226XM, AC PS,24DI DC/16DO RELAY
320 mA; 40 to 160 mA (240 V); 80 to 320 mA (120 V); output current for expansion modules (5 V DC) 1000 mA
Encoder supply
24 V encoder supply
● 24 V
Yes; Permissible range: 20.4V to 28.8V
● short-circuit protection
Yes; electronic at 1.5 A
● Output current, max.
400 mA
Memory
Number of memory modules (optional)
1; pluggable memory module, content identical with integral EEPROM
Data and program memory
● Data memory, max.
10 kbyte
● Program memory, max.
16 kbyte
Backup
● present
Yes; Program: Entire program maintenance-free on integral EEPROM, programmable via CPU; data: Entire DB 1 loaded from PG/PC maintenance-free on integral EEPROM, current values of DB 1 in RAM, retentive memory bits, timers, counters, etc. maintenance-free via high-performance capacitor; optional battery for long-term buffering
Battery
Backup battery
● Backup time, max.
190 h; (min. 120 h at 40 °C); 200 days (typ.) with optional battery module
CPU processing times
for bit operations, max.
0.37 µs
Counters, timers and their retentivity
S7 counter
● Number
256
of which retentive with battery
— can be set
Yes; via high-performance capacitor or battery
— lower limit
1
— upper limit
256
Counting range
— lower limit
0
— upper limit
32 767
S7 times
● Number
256
of which retentive with battery
— can be set
Yes; via high-performance capacitor or battery
— upper limit
65
Time range
— lower limit
1 ms
— upper limit
54 min; 4 timers: 1 ms to 30 s; 16 timers: 10 ms to 5 min; 236 timers: 100 ms to 54 min
Data areas and their retentivity
Flag
● Number, max.
32 byte
● Retentivity available
Yes; M 0.0 to M 31.7
● of which retentive with battery
0 to 255, via high-performance capacitor or battery, adjustable
● of which retentive without battery
0 to 112 in EEPROM, adjustable
Hardware configuration
Expansion devices, max.
7; Only expansion modules of the S7-22x series can be used. Due to the limited output current, the use of expansion modules may be limited.
Connectable programming devices/PCs
SIMATIC PG/PC, standard PC
Expansion modules
● Analog inputs/outputs, max.
35; max. 28 inputs and 7 outputs (EM) or max. 0 inputs and 14 outputs (EM)
● Digital inputs/outputs, max.
148; max. 128 inputs and 120 outputs (CPU+EM)
● AS-Interface inputs/outputs max.
31; AS-Interface slaves (CP 243-2)
Digital inputs
Number of digital inputs
24
m/p-reading
Yes; optionally, per group
Input voltage
● Rated value, DC
24 V
● for signal "0"
0 to 5 V
● for signal "1"
min. 15 V
Input current
● for signal "1", typ.
4 mA
Input delay (for rated value of input voltage)
for standard inputs
— Parameterizable
Yes; all
— at "0" to "1", min.
0.2 ms
— at "0" to "1", max.
12.8 ms
for interrupt inputs
— Parameterizable
Yes; I 0.0 to I 0.3
for counter/technological functions
— Parameterizable
Yes; (E0.0 to E1.5) 30 kHz
Cable length
● Cable length, shielded, max.
500 m; Standard input: 500 m, high-speed counters: 50 m
● Cable length unshielded, max.
300 m; not for high-speed signals
Digital outputs
Number of digital outputs
16; Relays
short-circuit protection
No; to be provided externally
Switching capacity of the outputs
● with resistive load, max.
2 A
● on lamp load, max.
200 W; 30 W with DC, 200 W with AC
Output voltage
● for signal "1", min.
L+/L1
Output current
● for signal "1" rated value
2 A
● for signal "0" residual current, max.
0 mA
Output delay with resistive load
● "0" to "1", max.
10 ms; all outputs
● "1" to "0", max.
10 ms; all outputs
Aggregate current of outputs (per group)
all mounting positions
— up to 40 °C, max.
10 A
horizontal installation
— up to 55 °C, max.
10 A
Relay outputs
● Number of operating cycles, max.
10 000 000; mechanically 10 million, at rated load voltage 100,000
Cable length
● Cable length, shielded, max.
500 m
● Cable length unshielded, max.
150 m
Analog inputs
Number of analog potentiometers
2; Analog potentiometer; resolution 8 bit
Encoder
Connectable encoders
● 2-wire sensor
Yes
— Permissible quiescent current (2-wire sensor), max.
1 mA
1st interface
Interface type
Integrated RS 485 interface
Physics
RS 485
Functionality
● MPI
Yes; As MPI slave for data exchange with MPI masters (S7-300/S7-400 CPUs, OPs, TDs, Push Button Panels); S7-200-internal CPU/CPU communication is possible in the MPI network with restrictions; transmission rates: 19.2/187.5 kbit/s
● PPI
Yes; with PPI protocol for program functions, HMI functions (TD 200, OP), S7-200-internal CPU/CPU communication ; transmission rates 9.6/19.2/187.5 kbit/s
● Serial data exchange
Yes; As freely programmable interface with interrupt facility for serial data exchange with third-party devices with ASCII protocol transfer rates: 0.3 / 0.6 / 1.2 / 2.4 / 4.8 / 9.6 / 19.2 / 38.4 kbit/s; at 1.2 to 38.4 kbit/s, the PC/PPI cable can also be used as RS232 / RS485 converter
MPI
● Transmission rate, min.
19.2 kbit/s
● Transmission rate, max.
187.5 kbit/s
2nd interface
Interface type
Integrated RS 485 interface
Physics
RS 485
Functionality
● MPI
Yes; As MPI slave for data exchange with MPI masters (S7-300/S7-400 CPUs, OPs, TDs, Push Button Panels); S7-200-internal CPU/CPU communication is possible in the MPI network with restrictions; transmission rates: 19.2/187.5 kbit/s
● PPI
Yes; with PPI protocol for program functions, HMI functions (TD 200, OP), S7-200-internal CPU/CPU communication ; transmission rates 9.6/19.2/187.5 kbit/s
● Serial data exchange
Yes; As freely programmable interface with interrupt facility for serial data exchange with third-party devices with ASCII protocol transfer rates: 0.3 / 0.6 / 1.2 / 2.4 / 4.8 / 9.6 / 19.2 / 38.4 kbit/s; at 1.2 to 38.4 kbit/s, the PC/PPI cable can also be used as RS232 / RS485 converter
MPI
● Transmission rate, min.
19.2 kbit/s
● Transmission rate, max.
187.5 kbit/s
Integrated Functions
Number of counters
6; High-speed counters (30 kHz each), 32 bits (incl. sign), can be used as up/down counters or for connecting 2 incremental encoders with 2 pulse trains offset by 90° (max. 20 kHz (A/B counters)); parameterizable enable and reset input; interrupt facilities (incl. call of subroutine with any content) when the setpoint is reached; reversal in counting direction, etc.
Counter frequency (counter) max.
30 kHz
Number of alarm inputs
4; 4 rising edges and/or 4 falling edges
Number of pulse outputs
2; High-speed outputs, 20 kHz, with interrupt option; pulse-width and frequency modulation option
Limit frequency (pulse)
20 kHz
Galvanic isolation
Galvanic isolation digital inputs
● between the channels
Yes; Optocoupler
● between the channels, in groups of
13; 13 and 11
Galvanic isolation digital outputs
● between the channels
Yes; Relays
● between the channels, in groups of
4; 4, 5 and 7
Permissible potential difference
between different circuits
500 V DC between 24 V DC and 5 V DC; 1500 V AC between 24 V DC and 230 V AC
Degree and class of protection
Degree of protection to EN 60529
● IP20
Yes
Ambient conditions
Environmental conditions
For further environmental conditions, see "Automation System S7-200, System Manual"
Operating temperature
● horizontal installation, min.
0 °C
● horizontal installation, max.
55 °C
● vertical installation, min.
0 °C
● vertical installation, max.
45 °C
Air pressure
● permissible range, min.
860 hPa
● permissible range, max.
1 080 hPa
Relative humidity
● Operation, min.
5 %
● Operation, max.
95 %; RH class 2 in accordance with IEC 1131-2
Configuration
programming
● Command set
Bit logic instructions, compare instructions, timer instructions, counter instructions, clock instructions, transmissions instructions, table instructions, logic instructions, shift and rotate instructions, conversion instructions, program control instructions, interrupt and communications instructions, logic stack instructions, integer maths, floating-point math instructions, numerical functions
● Program processing
free cycle (OB 1), interrupt-controller, time-controlled (1 to 255 ms)
● Program organization
1 OB, 1 DB, 1 SDB subroutines with/without parameter transfer
