6ES7671-0CC02-0YA0 SIMATIC WinAC Basis V4.0

6ES7671-0CC02-0YA0 SIMATIC WinAC Basis V4.0

Product Code: 6ES7671-0CC02-0YA0

Availability: In Stock

Price: $822.00
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6ES7671-0CC02-0YA0
SIMATIC WINAC BASIS V4.0, SINGLE LICENSE F. 1 INSTALL., R-SW, SW AND DOCU. ON CD, LICENSE KEY ON FD, CLASS A, 3 LANGUAGES (G,E,F), EXECUTABLE UNDER WIN 2000/XP, REFERENCE-HW: SIMATIC PC
Memory
Work memory
● Integrated PC RAM can be used
Load memory
● integrated RAM, max. PC RAM can be used
CPU processing times
for bit operations, typ. 0.2 µs; (typ.), reference platform Pentium 400 MHz
for fixed point arithmetic, typ. 0.06 µs; (typ.), reference platform Pentium 400 MHz
for floating point arithmetic, typ. 0.13 µs; (typ.), reference platform Pentium 400 MHz
CPU-blocks
DB
● Number, max. Limited only by available PC work memory
● Size, max. 64 kbyte
FB
● Number, max. Limited only by available PC work memory
● Size, max. 64 kbyte
FC
● Number, max. Limited only by available PC work memory
● Size, max. 64 kbyte
OB
● Size, max. 64 kbyte
● Number of time alarm OBs 1
● Number of delay alarm OBs 1
● Number of time interrupt OBs 5
● Number of process alarm OBs 1
Nesting depth
● per priority class 24
● additional within an error OB 24
Counters, timers and their retentivity
S7 counter
● Number 512
Retentivity
— can be set Yes
— lower limit 0
— upper limit 511
— preset 8
Counting range
— can be set Yes
— lower limit 1
— upper limit 999
IEC counter
● present Yes
● Type SFB
S7 times
● Number 512
Retentivity
— lower limit 511
— upper limit 0
Time range
— lower limit 10 ms
— upper limit 9 990 s
IEC timer
● present Yes
● Type SFB
Data areas and their retentivity
Retentivity without UPS and PS Extension Board none
Retentivity with UPS all data
Flag
● Number, max. 2 kbyte
● of which retentive MB 0 to MB 2047
● Retentivity preset 16
● Number of clock memories 8
Address area
I/O address area
● Inputs 16 kbyte
● Outputs 16 kbyte
of which, distributed
— MPI/DP interface, inputs 1 kbyte
— MPI/DP interface, outputs 1 kbyte
— DP interface, inputs 16 kbyte; Via CP 5613
— DP interface, outputs 16 kbyte; Via CP 5613
Process image
● Inputs, adjustable 8 kbyte
● Outputs, adjustable 8 kbyte
● Inputs, default 512 byte
● Outputs, default 512 byte
Subprocess images
● Number of subprocess images, max. 15
Digital channels
● Inputs 131 072
● Outputs 131 072
Analog channels
● Inputs 8 192
● Outputs 8 192
Hardware configuration
Number of DP masters
● overall 4
● Integrated 1; via CP 5611/integrated DP interface of the SIMATIC PC
● Via CP 4; CP 5613
Number of operable FMs and CPs (recommended)
● FM FM distributed: FM 350-1 / 350-2, FM 351, FM 352
● CP, point-to-point CP 340, CP 341 supports the necessary mechanisms
● CP, LAN Over PC CP
Time of day
Clock
● Hardware clock (real-time clock) Yes
● battery-backed and synchronizable Yes
Interfaces
1st interface
Interface type CP 5611, SIMATIC PC integrated
Physics RS 485 / PROFIBUS
Isolated Yes
Functionality
● MPI No
● DP master Yes
● DP slave No
DP master
● Number of connections, max. 8
● Transmission rate, max. 12 Mbit/s
● Number of DP slaves, max. 32
Services
— PG/OP communication Yes
— Routing Yes
— S7 communication Yes
— Equidistance mode support No
— SYNC/FREEZE Yes
— Activation/deactivation of DP slaves Yes
— Direct data exchange (slave-to-slave communication) No
— DPV0 Yes
— DPV1 No
Address area
— Inputs, max. 16 kbyte
— Outputs, max. 16 kbyte
User data per DP slave
— User data per DP slave, max. 244 byte; 244 byte / 244 byte
2nd interface
Interface type CP 5613
Physics RS 485 / PROFIBUS
Isolated Yes
Functionality
● MPI No
● DP master Yes
● DP slave No
DP master
● Number of connections, max. 32
● Transmission rate, max. 12 Mbit/s
● Number of DP slaves, max. 125
Services
— PG/OP communication Yes
— Routing Yes
— S7 communication Yes
— Equidistance mode support Yes
— SYNC/FREEZE Yes
— Activation/deactivation of DP slaves Yes
— Direct data exchange (slave-to-slave communication) No
— DPV0 Yes
— DPV1 Yes
Address area
— Address area, max. 16 kbyte; 16 KB /16 KB
User data per DP slave
— User data per DP slave, max. 244 byte; 244 byte / 244 byte
Isochronous mode
Isochronous operation (application synchronized up to terminal) No
Communication functions
PG/OP communication Yes
Global data communication
● supported No
S7 basic communication
● supported No
S7 communication
● as server Yes
● As client Yes
Number of connections
● overall 64
● usable for PG communication
— reserved for PG communication 1
● usable for OP communication
— reserved for OP communication 1
S7 message functions
Number of login stations for message functions, max. 64
Process diagnostic messages Yes; Alarm_S
Test commissioning functions
Status block Yes
Single step Yes
Status/control
● Status/control variable Yes
Forcing
● Forcing No
Diagnostic buffer
● present Yes
● Number of entries, max.
— preset 120
Hardware requirements
Hardware required Accessories: color monitor, keyboard, mouse or pointer for Windows
Main memory, min. 128 Mbyte
Required memory on hard disk, min. 100 Mbyte
Processor Intel Pentium 800 MHz
Operating systems
Configuration
Software interface C/C++ with WinAC ODK V4.0
Configuration software
● STEP 7 Yes; V5.2 or higher
programming
● Nesting levels 8
Programming language
— LAD Yes
— FBD Yes
— STL Yes
— SCL Yes
— CFC Yes
— GRAPH Yes
— HiGraph® Yes
Software libraries
— Easy Motion Control Yes
Know-how protection
● User program protection/password protection No
