6ES7138-4FB02-0AB0 ET200S, EL-MOD., 4 F-DO, DC 24V/2A

6ES7138-4FB02-0AB0 ET200S, EL-MOD., 4 F-DO, DC 24V/2A

Product Code: 6ES7138-4FB02-0AB0

Availability: In Stock

Price: $143.85
Qty:
Add to Wish List
Add to Compare


Artikelnummer 6ES7138-4FB02-0AB0
SIMATIC DP, ELECTRON. MODULE F. ET200S, 4 F-DO PROFISAFE, DC 24V/2A, 30 MM WIDTH UP TO CATEGORY 4 (EN954-1) ALSO USEABLE IN PROFINET- NETWORKS WITH IM151-3 HF
Supply voltage
Load voltage L+
● Rated value (DC) 24 V
● Reverse polarity protection No
Input current
from load voltage L+ (without load), max. typ. 100 mA
from backplane bus 3.3 V DC, max. 28 mA
Power loss
Power loss, typ. 3.5 W
Digital outputs
Number of digital outputs 4
Limitation of inductive shutdown voltage to typ. (L+) -47 V
Controlling a digital input No
Switching capacity of the outputs
● Lamp load, max. 10 W
Load resistance range
● lower limit 12 Ω
● upper limit 1 kΩ
Output voltage
● for signal "1", min. L+ (-2,0 V), current sourcing switch: L+ (-1,5 V), voltage drop on current sinking switch: max. 0.5 V
Output current
● for signal "1" rated value 2 A
● for signal "1" permissible range for 0 to 60 °C, min. 20 mA
● for signal "1" permissible range for 0 to 60 °C, max. 2.4 A
● for signal "0" residual current, max. 0.5 mA; Current-sourcing: max. 0.5 mA; Current sinking: max. 4 mA
Parallel switching of 2 outputs
● for uprating No
● for redundant control of a load No
Switching frequency
● with resistive load, max. 30 Hz
● with inductive load, max. 0.1 Hz
● on lamp load, max. 10 Hz
Total current of the outputs (per group)
all mounting positions
— up to 60 °C, max. 4 A
horizontal installation
— up to 40 °C, max. 6 A
— up to 55 °C, max. 5 A
vertical installation
— up to 40 °C, max. 4 A
Cable length
● Cable length, shielded, max. 200 m
● Cable length unshielded, max. 200 m
Interrupts/diagnostics/status information
Diagnostic messages
● Diagnostic functions Yes
● Wire-break Yes
● Short-circuit Yes
Diagnostics indication LED
● Group error SF (red) Yes
● Status indicator digital output (green) Yes
Galvanic isolation
Galvanic isolation digital outputs
● between the channels No
● between the channels and the backplane bus Yes
● between the channels and the load voltage L+ No
Standards, approvals, certificates
Highest safety class achievable in safety mode
● acc. to EN 954 Cat. 4
● acc. to IEC 61508 SIL 3
Dimensions
Width 30 mm
Height 81 mm
Depth 52 mm
Weights
Weight, approx. 85 g
last modified: 21.08.2014
