6ES7135-4MB00-0AB0 ET200S, EL-MOD., 2AO HF I,+/-20MA,4-20MA

6ES7135-4MB00-0AB0 ET200S, EL-MOD., 2AO HF I,+/-20MA,4-20MA

Product Code: 6ES7135-4MB00-0AB0

Availability: In Stock

Price: $215.09
Qty:
Add to Wish List
Add to Compare


Artikelnummer 6ES7135-4MB00-0AB0
SIMATIC DP, ELECTRONIC MODULE 2 AO HIGH FEATURE I FOR ET 200S, 15 MM WIDE, +/-20MA; 15 BIT + SIGN, 4 .. 20MA; 15 BIT, OPERATIONAL LIMITS +/-0.05% WITH LED SF (GROUP FAULT)
Supply voltage
Load voltage L+
● Rated value (DC) 24 V; From power module
● Reverse polarity protection Yes
Input current
from load voltage L+ (without load), max. 150 mA
from backplane bus 3.3 V DC, max. 10 mA
Power losses
Power loss, max. 3 W
Address area
Address space per module
● Address space per module, max. 4 byte
Analog outputs
Number of analog outputs 2
Current output, no-load voltage, max. 18 V
Cycle time (all channels) max. 1.5 ms
Output ranges, current
● -20 to +20 mA Yes
● 4 to 20 mA Yes
Connection of actuators
● for current output two-wire connection Yes
● for current output four-wire connection No
Load impedance (in rated range of output)
● with current outputs, max. 500 Ω
● with current outputs, inductive load, max. 1 mH
Destruction limits against externally applied voltages and currents
● Voltages at the outputs towards MANA 15 V; max. 15 V continuous; 75 V for max. 1 s (mark to space ratio 1:20)
● Current, max. 50 mA
Cable length
● Cable length, shielded, max. 200 m
Analog value creation
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max. 16 bit; +/-20 mA: 15 bits, 4 to 20 mA: 15 bits + sign
Settling time
● for resistive load 0.25 ms
● for capacitive load 1 ms
● for inductive load 0.5 ms
Errors/accuracies
Output ripple (based on output area, bandwidth 0 to 50 kHz), (+/-) 0.02 %
Linearity error (relative to output range), (+/-) 0.02 %
Temperature error (relative to output range), (+/-) 0.001 %/K
Repeat accuracy in steady state at 25 °C (relative to output area), (+/-) 0.01 %
Operational limit in overall temperature range
● Current, relative to output area, (+/-) 0.05 %
Basic error limit (operational limit at 25 °C)
● Current, relative to output area, (+/-) 0.01 %
Interrupts/diagnostics/status information
Substitute values connectable Yes; 0 to 65535 (range of values must be within the rated range)
Diagnostic messages
● Wire break Yes
● Group error Yes
Diagnostics indication LED
● Group error SF (red) Yes
Parameter
Remark 7 byte
Output type/range deactivated / +/-20 mA / 4 to 20 mA
Diagnosis: wire break Disable / enable
Group diagnostics Disable / enable
Behavior on CPU/Master STOP Output current and de-energized/substitute a value/keep last value
Galvanic isolation
Galvanic isolation analog outputs
● Galvanic isolation analog outputs Yes
● between the channels No
● between the channels and the backplane bus Yes
● between the channels and the load voltage L+ Yes
Permissible potential difference
between MANA and M internally (UISO) 75 VDC / 60 VAC
Dimensions
Width 15 mm
Height 81 mm
Depth 52 mm
Weights
Weight, approx. 40 g
last modified: 17.09.2014
