6ES7135-4LB02-0AB0 ET200S, EL-MOD., 2AO HF U, +/-10V, 1-5V

6ES7135-4LB02-0AB0 ET200S, EL-MOD., 2AO HF U, +/-10V, 1-5V

Product Code: 6ES7135-4LB02-0AB0

Availability: In Stock

Price: $102.75
Qty:
Add to Wish List
Add to Compare


Artikelnummer 6ES7135-4LB02-0AB0
SIMATIC DP, ELECTRONIC MODULE 2 AO U HIGH FEATURE FOR ET 200S, 15 MM WIDE, CYCLE TIME PER MODULE: 0.5MS, +/-10V; 15 BIT + SIGN, 1 .. 5V; 15 BIT, OPERATIONAL LIMITS +/-0.07% WITH LED SF (GROUP FAULT)
Supply voltage
Load voltage L+
● Rated value (DC) 24 V
● Reverse polarity protection Yes
Input current
from load voltage L+ (without load), max. 80 mA
from backplane bus 3.3 V DC, max. 10 mA
Power loss
Power loss, max. 1.2 W
Address area
Address space per module
● Address space per module, max. 4 byte
Analog outputs
Number of analog outputs 2
Voltage output, short-circuit protection Yes
Voltage output, short-circuit current, max. 25 mA
Cycle time (all channels) max. 0.5 ms; At max. 0.5 µF
Output ranges, voltage
● 1 to 5 V Yes; -5 to +5 V also implemented
● -10 to +10 V Yes
Connection of actuators
● for voltage output two-wire connection Yes
● for voltage output four-wire connection Yes
Load impedance (in rated range of output)
● with voltage outputs, min. 1 kΩ
● with voltage outputs, capacitive load, max. 0.5 µF
Destruction limits against externally applied voltages and currents
● Voltages at the outputs towards MANA 15 V; as required
Cable length
● Cable length, shielded, max. 200 m; 100m if Twa < 2ms
Analog value generation
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max. 16 bit; 15 bits + sign
Settling time
● for resistive load 0.2 ms
● for capacitive load 0.5 ms; At max. 0.5 µF
● for inductive load 0.5 ms
Errors/accuracies
Output ripple (based on output area, bandwidth 0 to 50 kHz), (+/-) 0.02 %
Linearity error (relative to output range), (+/-) 0.01 %
Crosstalk between the outputs, min. 60 dB
Repeat accuracy in steady state at 25 °C (relative to output area), (+/-) 0.01 %
Operational error limit in overall temperature range
● Voltage, relative to output area, (+/-) 0.1 %
Basic error limit (operational limit at 25 °C)
● Voltage, relative to output area, (+/-) 0.05 %
Isochronous mode
Isochronous mode (application synchronized up to terminal) Yes
Interrupts/diagnostics/status information
Substitute values connectable Yes
Diagnostic messages
● Diagnostic information readable Yes
● Short-circuit Yes
● Group error Yes
Diagnostics indication LED
● Group error SF (red) Yes
Parameter
Remark 7 byte
Output type/range deactivated / 1 to 5 V / +/ -10 V / +/- 5 V
Diagnostics short-circuit Disable / enable
Interference frequency suppression No
Group diagnostics Disable / enable
Behavior on CPU/master STOP Output current and de-energized/substitute a value/keep last value
Galvanic isolation
Galvanic isolation analog outputs
● between the channels No
● between the channels and the backplane bus Yes
● between the channels and the load voltage L+ Yes
Permissible potential difference
between MANA and M internally (UISO) 75 VDC / 60 VAC
Isolation
Isolation tested with 500 V DC
Dimensions
Width 15 mm
Height 81 mm
Depth 52 mm
Weights
Weight, approx. 40 g
last modified: 31.07.2014
