6ES7135-4LB01-0AB0 ET200S, EL-MOD., 2AO HF U, +/-10V, 1-5V

6ES7135-4LB01-0AB0 ET200S, EL-MOD., 2AO HF U, +/-10V, 1-5V

Product Code: 6ES7135-4LB01-0AB0

Availability: In Stock

Price: $123.30
Qty:
Add to Wish List
Add to Compare


SIMATIC DP, ELECTRONIC MODULE 2 AO HIGH FEATURE U FOR ET 200S, 15 MM WIDE, +/-10V; 15 BIT + SIGN, 1 .. 5V; 15 BIT, OPERATIONAL LIMITS +/-0.07% WITH LED SF (GROUP FAULT)
Supply voltage
Load voltage L+
Rated value (DC) 24 V; From power module
Reverse polarity protection Yes
Input current
from load voltage L+ (without load), max. 130 mA
from backplane bus 3.3 V DC, max. 10 mA
Power losses
Power loss, max. 2 W
Address area
Address space per module
Address space per module, max. 4 byte
Analog outputs
Number of analog outputs 2
Voltage output, short-circuit protection Yes
Voltage output, short-circuit current, max. 25 mA
Cycle time (all channels) max. 2.5 ms
Output ranges, voltage
1 to 5 V Yes
-10 to +10 V Yes
Connection of actuators
for voltage output two-wire connection Yes; Without compensation of the line resistances
for voltage output four-wire connection Yes
Load impedance (in rated range of output)
with voltage outputs, min. 1 kΩ
with voltage outputs, capacitive load, max. 1 µF
Destruction limits against externally applied voltages and currents
Voltages at the outputs towards MANA 15 V; max. 15 V continuous; 75 V for max. 1 s (mark to space ratio 1:20)
Current, max. 50 mA; DC
Cable length
Cable length, shielded, max. 200 m
Analog value creation
Integrations and conversion time/resolution per channel
Resolution with overrange (bit including sign), max. 16 bit; 1 to 5 V: 14 bits, +/-10 V: 16 bits
Basic conversion time, ms 1,0
Settling time
for resistive load 0.1 ms
for capacitive load 0.5 ms
for inductive load 0.5 ms
Errors/accuracies
Output ripple (based on output area, bandwidth 0 to 50 kHz), (+/-) 0.02 %
Linearity error (relative to output range), (+/-) 0.02 %
Temperature error (relative to output range), (+/-) 0.0010 %/K
Crosstalk between the outputs, min. 60 dB
Repeat accuracy in steady state at 25 °C (relative to output area), (+/-) 0.01 %
Operational limit in overall temperature range
Voltage, relative to output area, (+/-) 0.07 %
Basic error limit (operational limit at 25 °C)
Voltage, relative to output area, (+/-) 0.03 %
Isochronous mode
Isochronous operation (application synchronized up to terminal) Yes
Interrupts/diagnostics/status information
Substitute values connectable Yes; Parameterizable; 0 to 65535 (value range must be within rated range)
Diagnostic messages
Diagnostic information readable Yes
Short circuit Yes
Group error Yes
Diagnostics indication LED
Group error SF (red) Yes
Parameter
Remark 7 byte
Output type/range deactivated / 1 to 5 V / +/ -10 V
Diagnosis: short circuit Disable / enable
Group diagnostics Disable / enable
Behavior on CPU/Master STOP Output current and de-energized/substitute a value/keep last value
Galvanic isolation
Galvanic isolation analog outputs
between the channels No
between the channels and the backplane bus Yes
between the channels and the load voltage L+ Yes
Permissible potential difference
between MANA and M internally (UISO) 75 VDC / 60 VAC
Isolation
Isolation checked with 500 V DC
Dimensions
Width 15 mm
Height 81 mm
Depth 52 mm
Weights
Weight, approx. 40 g
Status Jun 16, 2014
