6ES7134-4GB51-0AB0 ET200S, EL-MOD., 2AI HS I-2DMU, 0-20MA,

6ES7134-4GB51-0AB0 ET200S, EL-MOD., 2AI HS I-2DMU, 0-20MA,

Product Code: 6ES7134-4GB51-0AB0

Availability: In Stock

Price: $143.85
Qty:
Add to Wish List
Add to Compare


Analog input module 2 AI

-
SIMATIC DP, ELECTRONIC MODULE ET 200S: 2AI HIGH SPEED I-2WIRE 4 - 20MA; 14BIT, 15 MM WIDTH, FOR 2-WIRE TRANSDUCER, CYCLE TIME OF THE MODULE: 1MS, WITH LED SF (GROUP FAULT)
Supply voltage
Load voltage L+
Rated value (DC) 24 V; From power module
short-circuit protection Yes; Destruction limit 35 mA per channel
Reverse polarity protection Yes
Input current
from load voltage L+ (without load), max. 35 mA; Without encoder supply voltage
from backplane bus 3.3 V DC, max. 10 mA
Encoder supply
Number of outputs 2
Output voltage L+ (-2.5 V), under load
short-circuit protection Yes; Electronic
Output current
Output current, rated value 90 mA; both channels
Output current, permissible range 0 to 90 mA
Power losses
Power loss, typ. 0.8 W
Address area
Address space per module
Address space per module, max. 4 byte
Analog inputs
Number of analog inputs 2
permissible input current for current input (destruction limit), max. 60 mA
Cycle time (all channels) max. 1 ms; Per module
Input ranges
Current Yes
Input ranges (rated values), currents
Input resistance (0 to 20 mA) 0.05 kΩ
4 to 20 mA Yes; on 50 ohms
Cable length
Cable length, shielded, max. 200 m
Analog value creation
Measurement principle Actual value encryption
Integrations and conversion time/resolution per channel
Resolution with overrange (bit including sign), max. 13 bit; 4 to 20 mA: 13 bits, 0 to 20 mA: 13 bits
Conversion time (per channel) 0.1 ms
Smoothing of measured values
Parameterizable Yes; In four stages by means of digital filtering
Step: None Yes; 1 x cycle time
Step: low Yes; 64 x cycle time
Step: Medium Yes; 128 x cycle time
Step: High Yes; 512x cycle time
Encoder
Connection of signal encoders
for current measurement as 2-wire transducer Yes
Burden of 2-wire transmitter, max. 670 Ω
Errors/accuracies
Linearity error (relative to input range), (+/-) 0.01 %
Temperature error (relative to input range), (+/-) 0.01 %/K
Crosstalk between the inputs, min. 50 dB
Repeat accuracy in steady state at 25 °C (relative to input area), (+/-) 0.05 %
Operational limit in overall temperature range
Current, relative to input area, (+/-) 0.3 %
Basic error limit (operational limit at 25 °C)
Current, relative to input area, (+/-) 0.2 %
Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency
Series mode interference (peak value of interference < rated value of input range), min. 70 dB
Isochronous mode
Isochronous operation (application synchronized up to terminal) Yes
Interrupts/diagnostics/status information
Alarms
Hardware interrupt Yes; Parameterizable
Diagnostic messages
Diagnostic functions Yes; Can be read out
Wire break Yes
Group error Yes
Overflow/underflow Yes
Diagnostics indication LED
Group error SF (red) Yes
Parameter
Remark 12 byte
Diagnosis: wire break Disable / enable
Measurement type/range Deactivated / 0 to 20 mA / 4 to 20 mA
Group diagnostics Disable / enable
Overflow/underflow Disable / enable
Galvanic isolation
Galvanic isolation analog inputs
between the channels No
between the channels and the backplane bus Yes
between the channels and the load voltage L+ No
Permissible potential difference
between MANA and M internally (UISO) 75 VDC / 60 VAC
Isolation
Isolation checked with 500 V DC
Dimensions
Width 15 mm
Height 81 mm
Depth 52 mm
Weights
Weight, approx. 40 g
Status Jun 16, 2014
