6AV7832-0BA10-1CA0 SIMATIC PANEL PC 577B, 15

6AV7832-0BA10-1CA0 SIMATIC PANEL PC 577B, 15" TOUCH

Product Code: 6AV7832-0BA10-1CA0

Availability: In Stock

Price: $1,918.00
Qty:
Add to Wish List
Add to Compare
Artikelnummer 6AV7832-0BA10-1CA0
SIMATIC PANEL PC 577B 15" TOUCH; 1024X768; WITHOUT OPERATING SYSTEM; AC 110/230V NAMUR; CEL M 440, 1,86 GHZ, 1MB L2; 1 GB RAM DDR2; 160GB SATA HDD 3,5"; DVD+/-R+/-RW; INTERFACES: 2X PCI, 2X ETHERNET 1GBIT/S, 4X USB 2.0 500MA, 1X FRONT-USB 2.0 500MA, 1X SERIAL (COM1) POWER CORD EU AND US INCLUDED
Operator control and monitoring
Accessory components Touch protective foil (not for Inox front)
Display
Screen diagonal 15 in
Size 15" TFT Touch
Resolution (pixels)
● Resolution (WxH in pixel) 1024 x 768
General features
● Front panel 15" TFT Touch
● Expansion components Uninterruptible power supply (USP), SIMATIC NET communication modules
Backlighting
● MTBF backlighting (at 25 °C) 50 000 h
Control elements
Function keys No
Mouse, at front No
Touch operation
● Design as touch screen Yes
Installation type/mounting
central design Yes
Distributed design No
Power losses
Power loss in full configuration 140 W max. (17.5 W included per slot)
Dimensions
Mounting cutout/device depth (W x H x T) 450x290 / 142 (incl. optical drive)
additional mounting depth (optical drive) 21 mm
Weights
Panel PC in central design, approx. 14 kg
last modified: 14.10.2014
