6AV6545-4BC16-0CX0 MOBILE PANEL 170
SIMATIC MOBILE PANEL 170 WITH INTEGRATED ENABLING BUTTON EMERGENCY-OFF BUTTON, HANDWHEEL, KEY SWITCH AND ILLUMINATED PUSHBUTTON UNIT, CONFIGURABLE W. PROTOOL/LITE VERSION V6.0+SP2 AND HIGHER
Display
Design of display
STN
Screen diagonal
5.7 in
Size
5.7"
Display type
STN, 16 colors
Number of colors
16
Color type
Colors
Resolution (pixels)
● Horizontal image resolution
320
● Vertical image resolution
240
● Resolution (WxH in pixel)
320 x 240
Backlighting
● MTBF backlighting (at 25 °C)
50 000 h
Control elements
Operating options
Keys and Touch
Function keys, programmable
14 function keys, 8 with LEDs
Keyboard
● Number of function keys
14
● freely inscribable membrane keys
Yes
● Number of function keys with LEDs
8
— Multi-key operation
Yes
— Number of multi-key operations
2
● System keys
— Number of configurable system keys
0
● Numeric/alphabetical input
Yes / Yes
— hexadecimal keyboard
Yes
● Multi-key operation
No
Touch operation
● Design as touch screen
Yes
Special operator controls
● Illuminated pushbutton
Yes
● Handwheel
Yes
Supply voltage
Supply voltage
via connection box
Processor
Processor type
RISC 32-bit, 66 MHz
Drives
Diskette drive
No
CD-ROM
No
Hard disk
No
Memory
Usable memory for user data
768 kbyte
Type of output
Info LED
No
Power LED
No
Error LED
No
Time of day
Clock
● Type
Hardware clock, no battery backup
● Hardware clock (real-time clock)
Yes
● Software clock
No
● Battery-backed
No
Interfaces
Interfaces
2 x RS232, 1 x RS422, 1 x RS485 (max. 12 Mbit/s)
Number of RS 485 interfaces
1
● Transmission rate, max.
12 Mbit/s
Number of USB interfaces
0
USB port
No
PC card slot
No
CF card slot
1 x CF card slot
Multi Media Card slot
No
Special interfaces
No
Industrial Ethernet
● Industrial Ethernet interface
No
● Industrial Ethernet status LED
0
Standards, approvals, certificates
Certifications
CE, cULus, SIBE
CE mark
Yes
Ambient conditions
Drop height
1.5 m
Operating temperature
● Operation
0 °C to +40 °C
Storage/transport temperature
● Transport, storage
-20 °C to +60 °C
Relative humidity
● Operation, max.
80 %
Operating systems
Operating system
Windows CE
Configuration
Configuration software
● Configuration tool
ProTool / Lite, Version 6 SP 2 and higher or WinCC flexible Compact Version 1 and higher (to be ordered separately)
● 1st configuration kit
ProTool / Lite
— Version
Version 6 SP 2
— Configuration tool
ProTool
— Type
Lite
● 2nd configuration kit
WinCC flexible Compact
— Version
Version 1
— Configuration tool
WinCC flexible
— Type
Compact
Languages
Online languages
● Number of online/runtime languages
5
Languages
● Languages per project
32
Functionality under WinCC (TIA Portal)
Libraries
Yes
Applications/options
none
● Internet Explorer
No
● Pocket Word
No
● Pocket Excel
No
● SIMATIC WinCC Sm@rtServer
No
Number of Visual Basic Scripts
● Debugging in the simulator
No
Task planner
Yes
Help system
Yes
● Number of characters per info text
70
● Number of tooltips
0
Message system
● Number of alarm classes
32
● Number of messages
2 000
● Bit messages
Yes
● Analog messages
Yes
● Number of bit messages
2 000
● Number of analog messages
50
● Telegram message procedure Alarm S
No
● System messages HMI
Yes
● System messages PLC
No
● System messages, other (SIMATIC S7, Sinumerik, Simotion, etc.)
No
● Message length (in characters)
70
● Lines
1
● Number of process values per message
8
● Acknowledgment groups
99
● Message indicator
Yes
● Acoustic feedback
Yes
● First/last value
Yes
Recipe administration
● Number of recipes
100
● Data records per recipe
200
● Entries per data record
200
● Recipe memory
32 KB integrated Flash, expandable
Variables
● Number of variables per device
1 024
● Number of variables per screen
50
● Limit values
Yes
● Multiplexing
Yes
● Structs
Yes
Images
● Number of configurable images
500
● Permanent window/default
Yes
● Start screen configurable
Yes
● Image selection by PLC
Yes
● Image number in the PLC
Yes
Image objects
● Text objects
2,500 text elements
● Fields per image
50
● Index of screen context
No
● Return
Yes
● Graphics object
Bit maps, vector graphics
Complex image objects
● Status/control
Not possible
● dynamic objects
Diagrams, bar graphs, sliders, invisible buttons
● Methods
Trend / profile
● Limit value lines
Yes
● Number of bars per chart
5
● Limit value lines
Yes
● Number of visible switches per project
1 000
Attributes for dynamic objects
● Color change
Yes
● X/Y movement
Yes
● Hide
Yes
● Angle of turn
No
Lists
● Number of text lists per project
300
● Number of graphics lists per project
100
Archiving
● Number of archives per device
0
● Number of measuring points per project
0
● Number of entries per archive
0
● Message archive
No
● Process value archive
No
● Archiving methods
— Sequential archive
No
— Short-term archive
No
● Memory location
— PC card
No
— CF card
No
— USB memory
No
— Ethernet
No
● Data storage format
— CSV
No
— TXT
No
● Online evaluation
— via trends
No
Filters
● cyclic
No
● Tolerance
No
● Change
No
Security
● Number of user groups
10
● Number of users
32
● Password export/import
Yes
Data carrier support
● PC card
No
● CF card
Yes
● Diskette drive
No
● Hard disk
No
● CD-ROM
No
Logging through printer
● Recording/Printing
Alarms, report (shift report), color print
Transfer (upload/download)
● Transfer of configuration
MPI/PROFIBUS DP, serial, automatic transfer recognition
Process coupling
● Connection to controller
S5, S7-200, S7- 300/400, TI 505, Win AC, SINUMERIK, SIMOTION, Allen Bradley (DF1), Allen Bradley (DF485), Mitsubishi (FX), OMRON (LINK/Multilink), Modicon (Modbus), weitere Fremdtreiber siehe Kapitel "Systemkopplungen"
